234 QuickScan™ I QD24XX
Multiple Labels Ordering by Code Symbology
This feature Specifies the transmission ordering by symbology type, when Multiple Labels per Frame is enabled.Up
to six symbologies can be selected. Zeroes must be added to pad the string to 12 characters if not using all six
symbologies.
The labels are ordered first as specified in the output mask. Lab
els present in the volume but not specified will be
transmitted as unspecified symbologies in random order as allowed by the reading time sequence. For each label
decoded in the volume the reader signals the standard beeper and LED indications.
To specify the symbology order:
1. Determine the symbologies and order you want to specify.
2. Use Table 44 on page 235 to find the hex values for up to six symbologies.
3. Go to page 80 and scan the ENTER/EXIT PROGRAMMING MODE bar code to enter Programming
Mode.
4. Scan the bar code: “SELECT SYMBOLOGIES FOR MULTIPLE LABELS ORDERING”.
5. Scan the appropriate two alphanumeric characters from th
e keypad in A
ppendix D, Keypad, that represent
the desired character/value in step 2 ab
ove.
6. Scan zeroes if needed to make a 12-character string.
7. When finished, scan the ENTER/EXIT PROGRAMMING
MODE
bar code to exit Programming Mode.
This completes the procedure. See Tab le 43 for some examples of how to set this feature.
Table 43. Multiple Labels Ordering by Code Symbology Examples
STEP ACTION EXAMPLES
1 Desired symbology
Code 39 Data Matrix Code 128 Aztec
2
Hex equivalent from
ASCII
Chart
24 0E 0C 4E
3 Scan ENTER/EXIT PROGRAMMING MODE
4
Scan SELECT SYMBOLOGIES FOR MULTIPLE LABELS ORDERING
5
Scan Two Characters From
Appendix D, Keypad
‘2’ and ‘4’ ‘0’ and ‘E’ ‘0’ and ‘C’ ‘4’ and ‘E’
RESULT
0x240E0C4E0000
6 Scan ENTER/EXIT PROGRAMMING MODE
Table 44 on page 235 shows the hex value associated with each symbology.
To Next Page
