Enter/Exit Programming Mode
170 QuickScan™ I QD24XX
Plessey Set Length 1
This feature specifies one of the bar code lengths for Plessey Length Control. Length 1 is the minimum label length
if in Variable Length Mode, or the first fixed length if in Fixed Length Mode. Length includes the bar code’s data
characters only. The length can be set from 01 to
50 characters.
Ta bl e 23 provides some examples for setting Length 1. See page 217 for detailed instructions on setting this feature.
Table 23. Plessey Length 1 Setting Examples
STEP ACTION EXAMPLES
1 Desired Setting 01 Characters 07 Characters 15 Characters 50 Characters
2 Scan ENTER/EXIT PROGRAMMING MODE
3 Scan SELECT Plessey LENGTH 1 SETTING
4
Scan Two Characters From
Appendix D, Keypad
‘0’ and ‘1’ ‘0’ and ‘7’ ‘1’ and ‘5’ ‘5’ AND ‘0’
5 Scan ENTER/EXIT PROGRAMMING MODE
$CPLL1
Select Plessey Set Length 1 Setting
Make a mistake? Scan the CANCEL bar code to abort and
not save the entry string. You can then start again at the
beginning.
~
CANCEL
DEFAULT
01 = Length 1 is 1 Character
