To Next Page

To Previous Page

Enter/Exit Programming Mode

Product Reference Guide 129

STANDARD 2 OF 5

The following options apply to the Standard 2 of 5 symbology.

Standard 2 of 5 Enable/Disable

When disabled, the reader will not read Standard 2 of 5 bar codes.

DEFAULT

$CS2EN00(CR)

Standard 2 of 5 = Disable

$CS2EN01(CR)

Standard 2 of 5 = Enable

Standard 2 of 5 Check Character Calculation

This option enables/disables calculation and verification of an optional Standard 2 of 5 check character.

DEFAULT

$CS2CC00(CR)

Standard 2 of 5 Check Character Calculation = Disable

$CS2CC01(CR)

Standard 2 of 5 Check Character Calculation = Enable

Default Chapter3
