To Next Page

To Previous Page

Enter/Exit Programming Mode

Product Reference Guide 137

CODE IATA

The following options apply to the IATA symbology.

IATA Enable/Disable

Enables/Disables the ability of the reader to decode IATA labels.

DEFAULT

$CIAEN00(CR)

IATA = Disable

$CIAEN01(CR)

IATA = Enable

IATA Check Character Transmission

Enables/Disables calculation and verification of an optional Industrial 2 of 5 check character.

$CIACT00(CR)

IATA Check Character Transmission = Disable

$CIACT01(CR)

IATA Check Character Transmission = Enable

DEFAULT

Default Chapter3
- Table of Contents3
