Dell S3048-ON User Manual

Dell(conf-policy-map-in)#service-queue 4 class-map cmap2
Dell(conf-policy-map-in)#exit
Dell(conf)#interface gigabitethernet 10/1
Dell(conf-if-gi-10/1)#service-policy input pmap
Important Points to Remember
• For route-maps with more than one match clause:
• Two or more match clauses within the same route-map sequence have the same match commands (though the values are
dierent), matching a packet against these clauses is a logical OR operation.
• Two or more match clauses within the same route-map sequence have dierent match commands, matching a packet against
these clauses is a logical AND operation.
• If no match is found in a route-map sequence, the process moves to the next route-map sequence until a match is found, or there are
no more sequences.
• When a match is found, the packet is forwarded and no more route-map sequences are processed.
• If a continue clause is included in the route-map sequence, the next or a specied route-map sequence is processed after a match
is found.
Conguration Task List for Route Maps
Congure route maps in ROUTE-MAP mode and apply the maps in various commands in ROUTER RIP and ROUTER OSPF modes.
The following list includes the conguration tasks for route maps, as described in the following sections.
• Create a route map (mandatory)
• Congure route map lters (optional)
• Congure a route map for route redistribution (optional)
• Congure a route map for route tagging (optional)
Creating a Route Map
Route maps, ACLs, and prex lists are similar in composition because all three contain lters, but route map lters do not contain the permit
and deny actions found in ACLs and prex lists.
Route map lters match certain routes and set or specic values.
To create a route map, use the following command.
• Create a route map and assign it a unique name. The optional permit and deny keywords are the actions of the route map.
CONFIGURATION mode
route-map map-name [permit | deny] [sequence-number]
The default is permit.
The optional seq keyword allows you to assign a sequence number to the route map instance.
Congured Route Map Examples
The default action is permit and the default sequence number starts at 10. When you use the keyword deny in conguring a route map,
routes that meet the match lters are not redistributed.
To view the conguration, use the show config command in ROUTE-MAP mode.
Dell(config-route-map)#show config
!
route-map dilling permit 10
Dell(config-route-map)#
Access Control Lists (ACLs)
111
