Upgrade Procedures

To nd the upgrade procedures, go to the Dell Networking OS Release Notes for your system type to see all the requirements needed to

upgrade to the desired Dell Networking OS version. To upgrade your system type, follow the procedures in the Dell Networking OS Release

Notes.

Get Help with Upgrades

Direct any questions or concerns about the Dell Networking OS upgrade procedures to the Dell Technical Support Center. You can reach

Technical Support:

• On the web: http://www.dell.com/support

• By email: Dell-Force10_Technical_Support@Dell.com

• By phone: US and Canada: 866.965.5800, International: 408.965.5800.

870 Upgrade Procedures
