1 Create the color-aware map QoS DSCP color map.
CONFIGURATION mode
qos dscp-color-map color-map-name
2 Create the color aware map prole.
DSCP-COLOR-MAP
dscp {yellow | red} {list-dscp-values}
3 Apply the map prole to the interface.
CONFIG-INTERFACE mode
qos dscp-color-policy color-map-name
Example: Create a DSCP Color Map
The following example creates a DSCP color map prole, color-awareness policy, and applies it to interface te 1/11.
Create the DSCP color map prole, bat-enclave-map, with a yellow drop precedence , and set the DSCP values to
9,10,11,13,15,16
Dell(conf)# qos dscp-color-map bat-enclave-map
Dell(conf-dscp-color-map)# dscp yellow 9,10,11,13,15,16
Dell (conf-dscp-color-map)# exit
Assign the color map, bat-enclave-map to interface gi 1/11.
Dell(conf)# interface gigabitethernet 1/11
Dell(conf-if-gi-1/11)# qos dscp-color-policy bat-enclave-map
Displaying DSCP Color Maps
To display DSCP color maps, use the show qos dscp-color-map command in EXEC mode.
Examples for Creating a DSCP Color Map
Display all DSCP color maps.
Dell# show qos dscp-color-map
Dscp-color-map mapONE
yellow 4,7
red 20,30
Dscp-color-map mapTWO
yellow 16,55
Display a specic DSCP color map.
Dell# show qos dscp-color-map mapTWO
Dscp-color-map mapTWO
yellow 16,55
Displaying a DSCP Color Policy Conguration
To display the DSCP color policy conguration for one or all interfaces, use the show qos dscp-color-policy {summary
[interface] | detail {interface}} command in EXEC mode.
Quality of Service (QoS)
651
