MIB Object OID Description
microseconds, that may be imposed by the
frame collector between receiving a frame
from an Aggregator Parser, and either
delivering the frame to its MAC Client or
discarding the frame.
dot3adAggPortListTable 1.2.840.10006.300.43.1.1.2 Contains a list of all the ports associated
with each Aggregator. Each LACP channel in
a device occupies an entry in the table.
dot3adAggPortListEntry 1.2.840.10006.300.43.1.1.2.1 Contains a list of ports associated with a
given Aggregator and indexed by the
ifIndex of the Aggregator.
dot3adAggPortListPorts 1.2.840.10006.300.43.1.1.2.1.1 Contains a complete set of ports currently
associated with the Aggregator.
Viewing the LAG MIB
• To view the LAG MIB generated by the system, use the following command.
snmpbulkget -v 2c -c LagMIB 10.16.148.157 1.2.840.10006.300.43.1.1.1.1.1
iso.2.840.10006.300.43.1.1.1.1.1.1258356224 = Hex-STRING: 00 01 E8 8A E8 46
iso.2.840.10006.300.43.1.1.1.1.1.1258356736 = Hex-STRING: 00 01 E8 8A E8 46
iso.2.840.10006.300.43.1.1.1.1.2.1258356224 = INTEGER: 32768
iso.2.840.10006.300.43.1.1.1.1.2.1258356736 = INTEGER: 32768
iso.2.840.10006.300.43.1.1.1.1.3.1258356224 = Hex-STRING: 00 01 E8 8A E8 44
iso.2.840.10006.300.43.1.1.1.1.3.1258356736 = Hex-STRING: 00 01 E8 8A E8 44
iso.2.840.10006.300.43.1.1.1.1.4.1258356224 = INTEGER: 1
iso.2.840.10006.300.43.1.1.1.1.4.1258356736 = INTEGER: 1
iso.2.840.10006.300.43.1.1.1.1.5.1258356224 = INTEGER: 127
iso.2.840.10006.300.43.1.1.1.1.5.1258356736 = INTEGER: 128
MIB Support to Display LLDP TLVs
Dell Networking provides MIB objects to display the information about an incoming LLDP TLVs advertised by neighbors. The
lldpRemUnknownTLVTable contains the information about an incoming LLDP TLVs that is not recognized by the receiving LLDP
neighbors. The following table lists the related MIB objects:
Table 84. MIB Objects for Displaying Unrecognized LLDP TLVs
MIB Object OID Description
lldpRemUnknownTLVTable 1.0.8802.1.1.2.1.4.3 This table contains information about
incoming TLV found in a single LLDP frame.
lldpRemUnknownTLVEntry 1.0.8802.1.1.2.1.4.3.1 Contains information about unrecognized
TLV received from a physical network
connection.
lldpRemUnknownTLVType 1.0.8802.1.1.2.1.4.3.1.1 Contains value extracted from the type eld
of the TLV.
lldpRemUnknownTLVInfo 1.0.8802.1.1.2.1.4.3.1.2 Contains value extracted from the value eld
of the TLV.
Simple Network Management Protocol (SNMP) 789
