• If one of the upstream interfaces in an uplink-state group goes down, either a user-congurable set of downstream ports or all the
downstream ports in the group are put in an Operationally Down state with an UFD Disabled error. The order in which downstream
ports are disabled is from the lowest numbered port to the highest.
• If one of the upstream interfaces in an uplink-state group that was down comes up, the set of UFD-disabled downstream ports
(which were previously disabled due to this upstream port going down) is brought up and the UFD Disabled error is cleared.
• If you disable an uplink-state group, the downstream interfaces are not disabled regardless of the state of the upstream interfaces.
• If an uplink-state group has no upstream interfaces assigned, you cannot disable downstream interfaces when an upstream link
goes down.
• To enable the debug messages for events related to a specied uplink-state group or all groups, use the debug uplink-state-
group [group-id] command, where the group-id is from 1 to 16.
• To turn o debugging event messages, use the no debug uplink-state-group [group-id] command.
• For an example of debug log message, refer to Clearing a UFD-Disabled Interface.
Conguring Uplink Failure Detection
To congure UFD, use the following commands.
1 Create an uplink-state group and enable the tracking of upstream links on the switch/router.
CONFIGURATION mode
uplink-state-group group-id
• group-id: values are from 1 to 16.
To delete an uplink-state group, use the no uplink-state-group group-id command.
2 Assign a port or port-channel to the uplink-state group as an upstream or downstream interface.
UPLINK-STATE-GROUP mode
{upstream | downstream} interface
For interface, enter one of the following interface types:
• 1 Gigabit Ethernet: enter gigabitethernet {slot/port | slot/port-range}
• 10 Gigabit Ethernet: enter tengigabitethernet {slot/port | slot/port-range}
Where port-range and port-channel-range specify a range of ports separated by a dash (-) and/or individual ports/port
channels in any order; for example:
upstream gigabitethernet 1/1-1/2,1/5,1/9,1/11-1/12
downstream port-channel 1-3,5
• A comma is required to separate each port and port-range entry.
To delete an interface from the group, use the no {upstream | downstream} interface command.
3 Congure the number of downstream links in the uplink-state group that will be disabled (Oper Down state) if one upstream link in the
group goes down.
UPLINK-STATE-GROUP mode
downstream disable links {number | all}
• number: species the number of downstream links to be brought down. The range is from 1 to 1024.
• all: brings down all downstream links in the group.
The default is no downstream links are disabled when an upstream link goes down.
NOTE
: Downstream interfaces in an uplink-state group are put into a Link-Down state with an UFD-Disabled error
message only when all upstream interfaces in the group go down.
To revert to the default setting, use the no downstream disable links command.
864
Uplink Failure Detection (UFD)
