Internet address is 1.1.0.1/24
IP UDP-Broadcast address is 1.1.255.255
MTU 1554 bytes, IP MTU 1500 bytes
LineSpeed auto
ARP type: ARPA, ARP Timeout 04:00:00
Last clearing of "show interface" counters 00:07:44
Queueing strategy: fifo
Input Statistics:
0 packets, 0 bytes
Time since last interface status change: 00:07:44
Congurations Using UDP Helper
When you enable UDP helper and the destination IP address of an incoming packet is a broadcast address, Dell Networking OS suppresses
the destination address of the packet.
The following sections describe various congurations that employ UDP helper to direct broadcasts.
• UDP Helper with Broadcast-All Addresses
• UDP Helper with Subnet Broadcast Addresses
• UDP Helper with Congured Broadcast Addresses
• UDP Helper with No Congured Broadcast Addresses
UDP Helper with Broadcast-All Addresses
When the destination IP address of an incoming packet is the IP broadcast address, Dell Networking OS rewrites the address to match the
congured broadcast address.
In the following illustration:
1 Packet 1 is dropped at ingress if you did not congure UDP helper address.
2 If you enable UDP helper (using the ip udp-helper udp-port command), and the UDP destination port of the packet matches
the UDP port congured, the system changes the destination address to the congured broadcast 1.1.255.255 and routes the packet
to VLANs 100 and 101. If you do not congure an IP broadcast address (using the ip udp-broadcast-address command) on
VLANs 100 or 101, the packet is forwarded using the original destination IP address 255.255.255.255.
Packet 2, sent from a host on VLAN 101 has a broadcast MAC address and IP address. In this case:
1 It is îš‚ooded on VLAN 101 without changing the destination address because the forwarding process is Layer 2.
2 If you enabled UDP helper, the system changes the destination IP address to the congured broadcast address 1.1.255.255 and
forwards the packet to VLAN 100.
3 Packet 2 is also forwarded to the ingress interface with an unchanged destination address because it does not have broadcast
address congured.
IPv4 Routing
373
