interface is physical, so represent this type of interface by a 0 bit, and the unused bit is always 0. These 2 bits are not given because they
are the most signicant bits, and leading zeros are often omitted.
NOTE: The interface index does not change if the interface reloads or fails over. If the unit is renumbered (for any reason) the
interface index changes during a reload.
To display the interface number, use the following command.
• Display the interface index number.
EXEC Privilege mode
show interface
Example of Deriving the Interface Index Number
To view the system image on Flash Partition A, use the chSysSwInPartitionAImgVers object or, to view the system image on Flash Partition
B, use the chSysSwInPartitionBImgVers object.
Table 87. MIB Objects for Viewing the System Image on Flash Partitions
MIB Object OID Description MIB
chSysSwInPartitionAImgVers 1.3.6.1.4.1.6027.3.10.1.2.8.1.11 List the version string of the
system image in Flash Partition
A.
Chassis MIB
chSysSwInPartitionBImgVers 1.3.6.1.4.1.6027.3.10.1.2.8.1.12 List the version string of the
system image in Flash Partition
B.
Chassis MIB
The system image can also be retrieved by performing an SNMP walk on the following OID: MIB Object is chSysSwModuleTable and the
OID is 1.3.6.1.4.1.6027.3.10.1.2.8.
Dell#show interfaces gigabitethernet 1/21
GigabitEthernet 1/21 is down, line protocol is down
Hardware is DellEth, address is f8:b1:56:82:de:70
Current address is f8:b1:56:82:de:70
Pluggable media not present
Interface index is 2099715
Monitor Port-Channels
To check the status of a Layer 2 port-channel, use f10LinkAggMib (.1.3.6.1.4.1.6027.3.2). In the following example, Po 1 is a switchport and Po
2 is in Layer 3 mode.
Example of SNMP Trap for Monitored Port-Channels
[senthilnathan@lithium ~]$ snmpwalk -v 2c -c public 10.11.1.1 .1.3.6.1.4.1.6027.3.2.1.1
SNMPv2-SMI::enterprises.6027.3.2.1.1.1.1.1.1 = INTEGER: 1
SNMPv2-SMI::enterprises.6027.3.2.1.1.1.1.1.2 = INTEGER: 2
SNMPv2-SMI::enterprises.6027.3.2.1.1.1.1.2.1 = Hex-STRING: 00 01 E8 13 A5 C7
SNMPv2-SMI::enterprises.6027.3.2.1.1.1.1.2.2 = Hex-STRING: 00 01 E8 13 A5 C8
SNMPv2-SMI::enterprises.6027.3.2.1.1.1.1.3.1 = INTEGER: 1107755009
SNMPv2-SMI::enterprises.6027.3.2.1.1.1.1.3.2 = INTEGER: 1107755010
SNMPv2-SMI::enterprises.6027.3.2.1.1.1.1.4.1 = INTEGER: 1
SNMPv2-SMI::enterprises.6027.3.2.1.1.1.1.4.2 = INTEGER: 1
SNMPv2-SMI::enterprises.6027.3.2.1.1.1.1.5.1 = Hex-STRING: 00 00
SNMPv2-SMI::enterprises.6027.3.2.1.1.1.1.5.2 = Hex-STRING: 00 00
SNMPv2-SMI::enterprises.6027.3.2.1.1.1.1.6.1 = STRING: "Gi 5/84 "
<< Channel member for Po1
SNMPv2-SMI::enterprises.6027.3.2.1.1.1.1.6.2 = STRING: "Gi 5/85 " << Channel member for Po2
dot3aCommonAggFdbIndex
SNMPv2-SMI::enterprises.6027.3.2.1.1.6.1.1.1107755009.1 = INTEGER: 1107755009
dot3aCommonAggFdbVlanId
SNMPv2-SMI::enterprises.6027.3.2.1.1.6.1.2.1107755009.1 = INTEGER: 1
dot3aCommonAggFdbTagConfig
796
Simple Network Management Protocol (SNMP)
