Important Points to Remember
• Typically, 5-second timeout and 3-second retry values on an SNMP server are sucient for both LAN and WAN applications. If you
experience a timeout with these values, increase the timeout value to greater than 3 seconds, and increase the retry value to greater
than 2 seconds on your SNMP server.
• User ACLs override group ACLs.
Set up SNMP
As previously stated, Dell Networking OS supports SNMP version 1 and version 2 that are community-based security models.
The primary dierence between the two versions is that version 2 supports two additional protocol operations (informs operation and
snmpgetbulk query) and one additional object (counter64 object).
SNMP version 3 (SNMPv3) is a user-based security model that provides password authentication for user security and encryption for data
security and privacy. Three sets of congurations are available for SNMP read/write operations: no password or privacy, password
privileges, password and privacy privileges.
You can congure a maximum of 16 users even if they are in dierent groups.
Creating a Community
For SNMPv1 and SNMPv2, create a community to enable the community-based security in Dell Networking OS.
The management station generates requests to either retrieve or alter the value of a management object and is called the SNMP manager.
A network element that processes SNMP requests is called an SNMP agent. An SNMP community is a group of SNMP agents and
managers that are allowed to interact. Communities are necessary to secure communication between SNMP managers and agents; SNMP
agents do not respond to requests from management stations that are not part of the community.
Dell Networking OS enables SNMP automatically when you create an SNMP community and displays the following message. You must
specify whether members of the community may only retrieve values (read), or retrieve and alter values (read-write).
22:31:23: %STKUNIT0-P:CP %SNMP-6-SNMP_WARM_START: Agent Initialized - SNMP WARM_START.
To choose a name for the community you create, use the following command.
• Choose a name for the community.
CONFIGURATION mode
snmp-server community name {ro | rw}
Example of Creating an SNMP Community
To view your SNMP conguration, use the show running-config snmp command from EXEC Privilege mode.
Dell(conf)#snmp-server community my-snmp-community ro
22:31:23: %STKUNIT0-P:CP %SNMP-6-SNMP_WARM_START: Agent Initialized - SNMP WARM_START.
Dell#show running-config snmp
!
snmp-server community mycommunity ro
Setting Up User-Based Security (SNMPv3)
When setting up SNMPv3, you can set users up with one of the following three types of conguration for SNMP read/write operations.
Users are typically associated to an SNMP group with permissions provided, such as OID view.
• noauth — no password or privacy. Select this option to set up a user with no password or privacy privileges. This setting is the basic
conguration. Users must have a group and prole that do not require password privileges.
Simple Network Management Protocol (SNMP)
767
