• weight: the range is from 1 to 255. The default is 120.
• ip-address mask: the IP address in dotted decimal format (A.B.C.D), and the mask in slash format (/x).
• access-list-name: the name of a congured IP ACL.
• Apply an additional number to the incoming or outgoing route metrics.
ROUTER RIP mode
offset-list access-list-name {in | out} offset [interface]
Congure the following parameters:
• prefix-list-name: the name of an established Prex list to determine which incoming routes are modied
• offset: the range is from 0 to 16.
• interface: the type, slot, and number of an interface.
To view the conguration changes, use the show config command in ROUTER RIP mode.
Debugging RIP
The debug ip rip command enables RIP debugging.
When you enable debugging, you can view information on RIP protocol changes or RIP routes.
To enable RIP debugging, use the following command.
•
debug ip rip [interface | database | events | trigger]
EXEC privilege mode
Enable debugging of RIP.
Example of the debug ip rip Command
The following example shows the conrmation when you enable the debug function.
Dell#debug ip rip
RIP protocol debug is ON
Dell#
To disable RIP, use the no debug ip rip command.
RIP Conguration Example
The examples in this section show the command sequence to congure RIPv2 on the two routers shown in the following illustration —
Core 2 and Core 3.
The host prompts used in the following example reect those names. The examples are divided into the following groups of command
sequences:
• Conguring RIPv2 on Core 2
• Core 2 RIP Output
• RIP Conguration on Core 3
• Core 3 RIP Output
• RIP Conguration Summary
676
Routing Information Protocol (RIP)
