Table 55. dot1p-priority Values and Queue Numbers
dot1p Queue Number
0 0
1 0
2 0
3 1
4 2
5 3
6 3
7 3
• Change the priority of incoming trac on the interface.
dot1p-priority
Example of Conguring a dot1p Priority on an Interface
Dell#configure terminal
Dell(conf)#interface gigabitethernet 1/1
Dell(conf-if-gi-1/1)#switchport
Dell(conf-if-gi-1/1)#dot1p-priority 1
Dell(conf-if-gi-1/1)#end
Honoring dot1p Priorities on Ingress Trac
By default, Dell Networking OS does not honor dot1p priorities on ingress trac.
You can congure this feature on physical interfaces and port-channels, but you cannot congure it on individual interfaces in a port
channel.
You can congure service-class dynamic dot1p from CONFIGURATION mode, which applies the conguration to all interfaces. A
CONFIGURATION mode service-class dynamic dot1p entry supersedes any INTERFACE entries. For more information, refer to Mapping
dot1p Values to Service Queues.
NOTE
: You cannot congure service-policy input and service-class dynamic dot1p on the same interface.
• Honor dot1p priorities on ingress trac.
INTERFACE mode
service-class dynamic dot1p
Example of Conguring an Interface to Honor dot1p Priorities on Ingress Trac
Dell#configure terminal
Dell(conf)#interface gigabitethernet 1/1
Dell(conf-if-gi-1/1)#service-class dynamic dot1p
Dell(conf-if-gi-1/1)#end
Priority-Tagged Frames on the Default VLAN
Priority-tagged frames are 802.1Q tagged frames with VLAN ID 0. For VLAN classication, these packets are treated as untagged.
However, the dot1p value is still honored when you congure service-class dynamic dot1p or trust dot1p.
638
Quality of Service (QoS)
