 The Slave can also be Delta temperature controller DTA, DTB, Delta servo ASDA and so on which are
compatible to Modbus protocol. Maximum 16 devices are connectable to the LINK.
 See the tables of special M and special D for the starting ID of Slave to be read/written and the number of
data to be read/written.
12. Communication addresses of devices in DVP series PLC:
Applicable to
Device Range Type Address
ES/EX/SS SA/SX/SC EH/EH2/SV
S 000 ~ 255 bit 0000 ~ 00FF 0 ~ 127
S 246 ~ 511 bit 0100 ~ 01FF
S 512 ~ 767 bit 0200 ~ 02FF
S 768 ~ 1,023 bit 0300 ~ 03FF
-
0 ~ 1,023 0 ~ 1,023
X 000 ~ 377 (Octal) bit 0400 ~ 04FF 0 ~ 177 0 ~ 177 0 ~ 377
Y 000 ~ 377 (Octal) bit 0500 ~ 05FF 0 ~ 177 0 ~ 177 0 ~ 377
T 000 ~ 255 bit/word 0600 ~ 06FF 0 ~ 127 0 ~ 255 0 ~ 255
M 000 ~ 255 bit 0800 ~ 08FF
M 256 ~ 511 bit 0900 ~ 09FF
M 512 ~ 767 bit 0A00 ~ 0AFF
M 768 ~ 1,023 bit 0B00 ~ 0BFF
M 1,024 ~ 1,279 bit 0C00 ~ 0CFF
0 ~ 1,279
M 1,280 ~ 1,535 bit 0D00 ~ 0DFF
M 1,536 ~ 1,791 bit B000 ~ B0FF
M 1,792 ~ 2,047 bit B100 ~ B1FF
M 2,048 ~ 2,303 bit B200 ~ B2FF
M 2,304 ~ 2,559 bit B300 ~ B3FF
M 2,560 ~ 2,815 bit B400 ~ B4FF
M 2,816 ~ 3,071 bit B500 ~ B5FF
M 3,072 ~ 3,327 bit B600 ~ B6FF
M 3,328 ~ 3,583 bit B700 ~ B7FF
M 3,584 ~ 3,839 bit B800 ~ B8FF
M 3,840 ~ 4,095 bit B900 ~ B9FF
-
0 ~ 4,095 0 ~ 4,095
0 ~ 199 16-bit bit/word 0E00 ~ 0EC7 0 ~ 127 0 ~ 199 0 ~ 199
bit 0EC8 ~ 0EFF
C
200 ~ 255 32-bit
word 0700 ~ 076F
232 ~ 255 200 ~ 255 200 ~ 255
D 000 ~ 256 word 1000 ~ 10FF
D 256 ~ 511 word 1100 ~ 11FF
D 512 ~ 767 word 1200 ~ 12FF
D 768 ~ 1,023 word 1300 ~ 13FF
D 1,024 ~ 1,279 word 1400 ~ 14FF
D 1,280 ~ 1,535 word 1500 ~ 15FF
0 ~ 1,311 0 ~ 4,999 0 ~ 9,999
