9 Application Instructions API 150-199
DVP-PLC Application Manual
9-61
API Mnemonic Operands Function
181
MOR P
Matrix ‘OR’ Operation
Controllers
ES/EX/SS SA/SX/SC EH/SV
Bit Devices Word Devices Program Steps Type
OP
X Y M S K H KnX KnY KnM KnS T C D E F
S
1
* * * * * * *
S
2
* * * * * * *
D * * * * * *
n * * *
MOR, MORP: 9 steps
PULSE 16-bit 32-bit
ES EX SS SA SX SC EH SV ES EX SS SA SX SC EH SV ES EX SS SA SX SC EH SV
Operands:
S
1
: Matrix source device 1 S
2
: Matrix source device 2. D: Operation result n: Array length
Explanations:
1. Range of n: K1 ~ K256
2. S
1
, and S
2
designate KnX, KnY, KnM and KnS; D designates KnYm KnM and KnS
3. SA/SX/SC can designate n = 4. EH/EH2/SV can designate n 4≦ .
4. See the specifications of each model for their range of use.
5. The two matrix sources S
1
and S
2
perform matrix ‘OR’ operation according to the array length n. The result is
stored in D.
6. Operation rule of matrix ‘OR’: The result will be 1 if either of the two bits is 1. The result is 0 only when both two
bits are 0.
Program Example:
When X0 = On, the 3 arrays of 16-bit registers D0 ~ D2 and the 3 arrays of 16-bit registers D10 ~ D12 will perform a
matrix ‘OR’ operation. The result will be stored in the 3 arrays of 16-bit registers D20 ~ D22.
X0
MOR D0 D10 D20 K3
1
11
000
11
0000
11
000
11
0000
11
000
11
0000
010101010101010
1010101010101010
1010101010101010
1
1
1
1
1
1
0
0
0
1
1
1
1
1
1
11
0
0
11
00
11
0
01
1
00
11
0
0
1
1
00
1
1
1
1
1
1
1
1
1
1
1
1
1111
1
1
1
1
1
1
1
1
b15 b0
MOR
Before
Execution
After
Execution
To Next Page
