Delta DVP-PM Series User Manual

3 Functions of Devices in DVP-PM
DVP-PM Application Manual
3-3
H Hex
H0000 ~ HFFFF (16-bit operation); H00000000 ~ HFFFFFFFF (32-bit
operation)
F Floating point
Displaying floating point value by 32-bit data complying with IEEE754
standard.
±1.1755X10
-38
~ ±3.4028X10
+38
*1: Non-latched area cannot be modified.
*2: Non-latched area, can be modified as latched area by changing the parameter settings
*3: Latched area, can be modified as non-latched area by changing the parameter settings
*4: Latched area, cannot be modified
*5: DVP20PM00M supports 3-axis linear interpolation and helical interpolation
 Settings of latched and non-latched memory devices:
*1: If you set D1200 = 0 and D1201 = 4095, DVP-PM will automatically ignore M1000 ~ M2999 and set M0 ~ M999 and M3000 ~
M4095 as latched area.
*2: K-1 refers to default = not latched.
*3: If you set D1210 = 0 and D1211 = 9999, DVP-PM will automatically ignore D1000 ~ D2999 and set D0 ~ D999 and D3000 ~
D9999 as latched areas.
General purpose Special auxiliary relay
M0 ~ M499 M500 ~ M999 M3000 ~ M4095 M1000 ~ M2999
Default:: not latched Default:: latched Default:: not latched
Allocated in the range of “general
purpose” M relays
M
(Auxiliary relay)
Start:: D1200 (K500)*1
End: D1201 (K999) *1
Some are latched and cannot be
modified.
10ms
T0 ~ T255
Default:: not latched
T
(Timer)
Start:: D1202 (K-1) *2
End: D1203 (K-1) *2
16-bit count up 32-bit count up/down
C0 ~ C99 C100 ~ C199
C200, C204
C208 ~ C219
C220 ~ C255
Default:: not latched Default:: latched Default:: not latched Default:: latched
C
(Counter)
Start:: D1204 (K100)
End: D1205 (K199)
Start:: D1206 (K220)
End: D1207 (K255)
Initial General purpose Latched
S0 ~ S9 S10 ~ S499 S500 ~ S1023
Default:: non-latched Default:: latched
S
(Step relay)
Start:: D1208 (K500), End: D1209 (K1023)
General purpose Latched Special register
D0 ~ D999 D3000 ~ D9999
D1000 ~ D2999
Allocated in the range of "general
purpose” registers
Default:: not latched Default:: latched
D
(Register)
Start:: D1210 (K200) *3
End: D1211 (K9999) *3
Some are latched and cannot be
modified.
