Delta DVP-PM Series User Manual

3 Functions of Devices in DVP-PM
DVP-PM Application Manual
3-5
3. Decimal value (DEC)
DVP-PLC appies decimal operation in situations below:
 Set value for timers and counters, e.g. TMR C0 K50. (K value)
 No. of S, M, T, C, D, E, F, P, I devices, e.g. M10, T30. (No. of device)
 For use of operand in API instructions, e.g. MOV K123 D0. (K value)
4. Binary coded decimal (BCD)
BCD format takes 1 digit or 4 bits to indicate a Decimal value, so that data of consecutive 16 bits indicates a
4-digit decimal value. Used mainly for reading values from DIP switches or sending data to 7-segement displays.
5. Hexadecimal value (HEX)
Occasion of using hexadecimal values:
 For use of operand in API instructions, e.g. MOV H1A2B D0。(H value)
Constant K:
Decimal value in PLC operation is attached with an “K”, e.g. K100 indicates the value 100 in Decimal format.
Exception:
When constant K is used with bit devices X, Y, M or S, the value specifed after K indicates the groups
of 4-bit unit, which forms a digit(4-bit), byte(8 bit), word(16bit), or double word(32-bit) data, e.g.
K2Y10, K4M100, representing Y10 ~ Y17 and M100~M115.
Constant H:
Hexadecimal value in PLC operation is attached with an “H”, e.g. H100 indicates the value 256 in Hex format.
Floating point F:
Floating point value in PLC operation is attached with an “F”, e.g. F3.123 refers to a floating point value, 3.123. 23.
Reference table:
Binary
(BIN)
Octal
(OCT)
Decimal
(DEC)
Binary Code Decimal
(BCD)
Hexadecimal
(HEX)
For DVP-PM internal operation
No. of device X,
Y
Constant K and No.
of device M, S, T, C,
D, V, Z, P
For DIP switch and 7-segment
display
Constant H
0000 0000 0 0 0 0 0 0 0 0 0 0 0
0000 0001 1 1 0 0 0 0 0 0 0 1 1
0000 0010 2 2 0 0 0 0 0 0 1 0 2
0 0 0 0 0 0 1 1 3 3 0 0 0 0 0 0 1 1 3
0000 0100 4 4 0 0 0 0 0 1 0 0 4
0000 0101 5 5 0 0 0 0 0 1 0 1 5
0 0 0 0 0 1 1 0 6 6 0 0 0 0 0 1 1 0 6
0 0 0 0 0 1 1 1 7 7 0 0 0 0 0 1 1 1 7
0000 1000 10 8 0 0 0 0 1 0 0 0 8
0000 1001 11 9 0 0 0 0 1 0 0 1 9
0000 1010 12 10 0 0 0 1 0 0 0 0 A
0000 1011 13 11 0001 0001 B
