OPERATION
3-48 EPT024619 Issue 1 June 2016
Barcode
To ensure consistent barcode quality is maintained, a shaft encoder should
be used to measure the production line speed. See “Shaft Encoder
Connection” on page 6-27.
To insert a barcode into the message design:
(1) Place the cursor where the barcode is required.
Note: If printing on multiple lines of text, position the cursor on the
bottom line. This ensures that the barcode will be fully printed.
(2) Select the Code icon.
(3) Select Static.
(4) The following barcode settings can be defined:
(5) Select Insert to confirm the settings and return to the Message
Designer.
Setting Name Explanation
Data Enter the barcode data.
Type Select the barcode type from the following options:
•Code 39
• Code 2 of 5 Interleaved
• Code 128
•Code 93
• Code UPC-A
•Code EAN
• Code Codabar
•Code 11
Width Select the barcode width.
Range: 1 - 4
Height Select the barcode height.
Range: 1 - 3
Enable text Enable or Disable human readable text.
