4 Micro Motion Series 1000 and Series 2000 Transmitters
Before You Begin
1.5.1 Component versions
In general, this manual documents transmitters with transmitter software rev5.0, connected to either a
standard core processor (v2.5) or an enhanced core processor (v3.21). Earlier versions of transmitter
and core processor software are similar but not identical. Significant differences between versions are
noted in the manual; however, not all differences are noted.
1.5.2 Terminology
Table 1-3 lists definitions for the terms and codes that are used in this manual.
Table 1-3 Terms and codes used in this manual
Term Definition
Series 1000 Refers to the following transmitters:
• Model 1500
• Model 1700
Series 2000 Refers to the following transmitters:
• Model 2500
• Model 2700
Model 1500 Refers to the following transmitter:
• Model 1500 with the analog outputs option board
Model 1700 Refers to the following transmitters:
• Model 1700 with the analog outputs option board
• Model 1700 with the intrinsically safe outputs option board
Model 2500 Refers to the following transmitter:
• Model 2500 with the configurable input/outputs option board
Model 2700 Refers to the following transmitters:
• Model 2700 with the analog outputs option board
• Model 2700 with the intrinsically safe outputs option board
• Model 2700 with the configurable input/outputs option board
AN Analog outputs option board. Available with the following transmitters:
• Model 1500 with the analog outputs option board
• Model 1700 with the analog outputs option board
• Model 2700 with the analog outputs option board
IS Intrinsically safe outputs option board. Available with the following transmitters:
• Model 1700 with the intrinsically safe outputs option board
• Model 2700 with the intrinsically safe outputs option board
CIO Configurable input/outputs option board. Available with the following transmitters:
• Model 2500 with the configurable input/outputs option board
• Model 2700 with the configurable input/outputs option board
