10 Micro Motion Series 1000 and Series 2000 Transmitters
Using the Transmitter Display
2.3 Using the optical switches
The
Scroll and Select optical switches are used to navigate the transmitter display. To activate an
optical switch, touch the glass in front of the optical switch or move your finger over the optical
switch close to the glass. The optical switch indicator will be solid red when a single switch is
activated, and will flash red when both switches are activated simultaneously.
2.4 Using the display
The display can be used to view process variable data or to access the transmitter menus for
configuration or maintenance.
2.4.1 Display language
The display can be configured for the following languages:
• English
•French
• Spanish
•German
Due to software and hardware restrictions, some English words and terms may appear in the
non-English display menus. For a list of the codes and abbreviations used on the display, see
Appendix H.
For information on configuring the display language, see Section 8.14.2.
In this manual, English is used as the display language.
2.4.2 Viewing process variables
In ordinary use, the
Process variable line on the display shows the configured display variables, and
the
Units of measure line shows the measurement unit for that process variable.
• See Section 8.14.6 for information on configuring the display variables.
• See Appendix H for information on the codes and abbreviations used on the display (e.g.,
SrC).
If more than one line is required to describe the display variable, the
Units of measure line alternates
between the measurement unit and the additional description. For example, if the display is showing a
mass inventory value, the
Units of measure line alternates between the measurement unit (G) and the
name of the inventory (
MASSI). For enhanced density or petroleum measurement variables, the
reference temperature is also shown.
WARNING
Removing the display cover in an explosive atmosphere can cause an
explosion.
When using the optical switches, do not remove the display cover. To activate an
optical switch, touch the glass of the display cover or move your finger over the
switch close to the glass.
