52 Micro Motion Series 1000 and Series 2000 Transmitters
Required Transmitter Configuration
6.4.5 Pressure units
The flowmeter does not measure pressure, but the transmitter can poll an external pressure
measurement device. The default pressure measurement unit is
PSI. See Table 6-7 for a complete list
of pressure measurement units. It is not necessary to match units between the transmitter and the
external pressure device – the transmitter will convert units for you.
6.5 Configuring the mA output(s)
See the Configuration and Use Manual Supplement for your transmitter for information and
instructions on configuring the mA output(s).
6.6 Configuring the frequency output(s)
See the Configuration and Use Manual Supplement for your transmitter for information and
instructions on configuring the frequency output(s).
6.7 Configuring the discrete output(s)
See the Configuration and Use Manual Supplement for your transmitter for information and
instructions on configuring the discrete output(s).
Table 6-7 Pressure measurement units
Pressure unit
Unit descriptionDisplay ProLink II Communicator
FTH2O Ft Water @ 68°F ftH2O Feet water @ 68 °F
INW4C In Water
@ 4°C inH2O @4DegC Inches water @ 4 °C
INW60 In Water @ 60°F inH2O @60DegF Inches water @ 60 °F
INH2O In Water @ 68°F inH2O Inches water @ 68 °F
mmW4C mm Water
@ 4°C mmH2O @4DegC Millimeters water @ 4 °C
mmH2O mm Water
@ 68°F mmH2O Millimeters water @ 68 °F
mmHG mm Mercury
@ 0°C mmHg Millimeters mercury @ 0 °C
INHG In Mercury @ 0°C inHg Inches mercury @ 0 °C
PSI PSI psi Pounds per square inch
BAR bar bar Bar
mBAR millibar mbar Millibar
G/SCM g/cm2 g/Sqcm Grams per square centimeter
KG/SCM kg/cm2 kg/Sqcm Kilograms per square centimeter
PA pascals Pa Pascals
KPA Kilopascals kPa Kilopascals
MPA megapascals MPa Megapascals
TORR Torr
@ 0 °C torr Torr @ 0 °C
ATM atms atms Atmospheres
