182 Micro Motion Series 1000 and Series 2000 Transmitters

Menu Flowcharts – Model 1500 AN Transmitters

C.4 ProLink II menus

Figure C-1 ProLink II main menu

File

Preferences

• Use External Temperature

• Enable Inventory Totals Reset

• Enable External Pressure Compensation

• Copper RTD

Installed options

Data Logging

(1)

Enable/Disable

Custody Transfer

Load from Xmtr to File

Save to Xmtr from File

License

Connect to Device

Disconnect

View Connection

Gas Unit Configurator

Meter Verification

Options

• ProLink II Language

• Error Log On

Tools Plug-insProLink

Configuration

Output Levels

Process Variables

Status

Alarm Log

Diagnostic Information

Calibration

Test

ED Totalizer Control

Totalizer Control

Core Processor Diagnostics

Finger Print

API Process Variables

ED Process Variables

(1) For information about using Data Logger, refer to the ProLink II manual.

Default Chapter3
- Table of Contents3
Chapter 1 Before You Begin11
- Overview11
- Safety11
- Determining Your Transmitter Type and Version11
  - Transmitter Type, Installation Type, and Outputs Option Board12
  - Version13
- Flowmeter Documentation13
- Using this Manual13
- Planning the Configuration15
- Pre-Configuration Worksheet16
- Micro Motion Customer Service17
Chapter 2 Using the Transmitter Display19
- Overview19
- Components19
- Using the Optical Switches20
- Using the Display20
Chapter 3 Connecting with Prolink II or Pocket Prolink Software25
- Overview25
- Requirements25
- Prolink II Configuration Upload/Download26
- Connecting from a PC to a Model 1700 or Model 2700 Transmitter26
- Connecting from a PC to a Model 1500 or Model 2500 Transmitter33
  - Connecting to the RS-485 Terminals or an RS-485 Network33
  - Hart/Bell 202 Connections36
- Prolink II Language37
Chapter 4 Connecting with the 275 HART Communicator or39
- Field Communicator39
Chapter 5 Flowmeter Startup45
- Flowmeter Startup45
  - Overview45
- Applying Power46
  - Communication Methods after Power-Up46
- Performing a Loop Test47
- Trimming the Milliamp Outputs48
- Zeroing the Flowmeter49
  - Preparing for Zero49
  - Zero Procedure50
Chapter 6 Required Transmitter Configuration53
- Overview53
- Characterizing the Flowmeter54
- Configuring the Channels57
- Configuring the Measurement Units57
- Configuring the Ma Output(S)62
- Configuring the Frequency Output(S)62
- Configuring the Discrete Output(S)62
- Configuring the Discrete Input63
- Establishing a Meter Verification Baseline63
Chapter 7 Using the Transmitter65
- Overview65
- Special Applications65
- Recording Process Variables66
- Viewing Process Variables66
- Viewing Transmitter Status and Alarms67
- Acknowledging Alarms69
- Using the Totalizers and Inventories70
  - Viewing the Totalizers and Inventories70
- Controlling Totalizers and Inventories71
Chapter 8 Optional Configuration75
- Overview75
- Configuration Map75
- How to Access a Parameter for Configuration75
- Configuring Standard Volume Flow Measurement for Gas77
  - Using the Gas Wizard77
- Creating Special Measurement Units78
  - About Special Measurement Units78
  - Special Measurement Unit Procedure79
- Configuring the Petroleum Measurement Application (API Feature)80
  - About the Petroleum Measurement Application80
- Configuring Cutoffs82
  - Cutoffs and Volume Flow83
  - Interaction with the AO Cutoffs83
- Configuring the Damping Values83
- Configuring the Update Rate84
  - Effects of Special Mode85
- Configuring the Flow Direction Parameter86
- Configuring Events89
  - Changing Event Setpoints from the Display89
- Configuring Slug Flow Limits and Duration90
- Configuring Fault Handling91
  - Status Alarm Severity91
  - Fault Timeout95
- Configuring the Display95
- Configuring Digital Communications97
- Configuring Device Settings97
- Configuring Sensor Parameters97
- Configuring Write-Protect Mode98
Chapter 9 Pressure Compensation, Temperature Compensation, and Polling99
- Overview99
- Pressure Compensation99
- External Temperature Compensation101
  - Configuring Polling103
Chapter 10 Measurement Performance107
- Overview107
- Meter Verification, Meter Validation, and Calibration107
- Performing Meter Verification111
- Performing Meter Validation128
- Performing Density Calibration129
  - Preparing for Density Calibration129
  - Density Calibration Procedures130
- Performing Temperature Calibration133
Chapter 11 Custody Transfer135
- Overview135
- Locale-Specific Commissioning135
- Configuring the Weights and Measures Approval Agency135
- Special Restrictions When Using Custody Transfer Transmitters136
- Switching between Security Breach and Secure Mode136
- Security Breach Mode136
  - Transmitter Outputs in Security Breach Mode137
  - Configuring the Totalizers in Security Breach Mode137
- Secure Mode137
Chapter 12 Troubleshooting139
- Overview139
- Guide to Troubleshooting Topics139
- Micro Motion Customer Service140
- Transmitter Does Not Operate140
- Transmitter Does Not Communicate140
- Zero or Calibration Failure141
- Fault Conditions141
- HART Output Problems141
- I/O Problems141
- 12.10 Simulation Mode144
- 12.11 Transmitter Status LED145
  - Model 1500/2500 Transmitters145
  - Model 1700/2700 Transmitters with Displays145
- 12.12 Status Alarms146
- 12.13 Checking Process Variables151
- 12.14 Diagnosing Wiring Problems154
  - Checking the Power Supply Wiring154
  - Checking the Sensor-To-Transmitter Wiring155
  - Checking Grounding155
  - Checking for RF Interference155
  - Checking the HART Communication Loop156
- 12.15 Checking the Communication Device156
- 12.16 Checking the Output Wiring and Receiving Device157
- 12.17 Checking Slug Flow157
- 12.18 Checking Output Saturation158
- 12.19 Setting the Loop Current Mode Parameter158
- 12.20 Checking the Flow Measurement Unit158
- 12.21 Checking the Upper and Lower Range Values159
- 12.22 Checking the Frequency Output Scale and Method159
- 12.23 Checking the Characterization159
- 12.24 Checking the Calibration159
- 12.25 Checking the Test Points159
  - Obtaining the Test Points160
  - Evaluating the Test Points160
  - Excessive Drive Gain161
  - Erratic Drive Gain161
  - Low Pickoff Voltage162
- 12.26 Checking the Core Processor162
  - Checking the Core Processor LED162
  - Core Processor Resistance Test (Standard Core Processor Only)165
- 12.27 Checking Sensor Coils and RTD167
  - 9-Wire Remote or Remote Core Processor with Remote Transmitter Installation167
  - 4-Wire Remote or Integral Installation168
Appendix A Default Values and Ranges173
- Overview173
- Most Frequently Used Defaults and Ranges173
Appendix B Flowmeter Installation Types and Components179
- Overview179
- Model 1500/2500 Transmitters179
- Model 1700/2700 Transmitters184
Appendix C Menu Flowcharts - Model 1500 an Transmitters191
- Overview191
- Model 1500 Output Board191
- Version Information191
- Prolink II Menus192
- C.4 Prolink II Menus192
- Communicator Menus195
- C.5 Communicator Menus195
Appendix D Menu Flowcharts - Model 2500 CIO Transmitters201
- Overview201
- Version Information201
- Prolink II Menus202
- Communicator Menus205
Appendix E Menu Flowcharts - Model 1700/2700 an Transmitters211
- Overview211
- Version Information211
- Prolink II Menus212
- Communicator Menus215
- Display Menus221
- E.5 Display Menus221
Appendix F Menu Flowcharts - Model 1700/2700 IS Transmitters229
- Overview229
- Version Information229
- Prolink II Menus230
- Communicator Menus233
- Display Menus239
- F.5 Display Menus239
Appendix G Menu Flowcharts - Model 2700 CIO Transmitters247
- Overview247
- Version Information247
- Prolink II Menus248
- G.3 Prolink II Menus248
- Communicator Menus251
- G.4 Communicator Menus251
- Display Menus257
- G.5 Display Menus257
Appendix H Display Codes and Abbreviations267
Appendix I NE53 History269
Index273
