30 Micro Motion Series 1000 and Series 2000 Transmitters
Connecting with the 275 HART Communicator or 375 Field Communicator
4.2.1 Viewing the device descriptions
HART Communicator 275
To view the device descriptions that are installed on your 275 HART Communicator:
1. Turn on the HART Communicator, but do not connect it to the transmitter.
2. When the words
No device found appear, press OK.
3. Select
OFFLINE.
4. Select
New Configuration.
5. Select
Micro Motion.
375 Field Communicator
To view the device descriptions that are installed on your 375 Field Communicator:
1. At the HART application menu, select
Utility.
2. Select
Available Device Descriptions.
3. Select
Micro Motion.
4.2.2 Using the 275 HART Communicator with the Model 2500
To use the 275 HART Communicator with the Model 2500 transmitter:
1. Turn on the HART Communicator and connect it to the transmitter. The
following warning message is displayed:
2. Press
Yes to continue using the 275 HART Communicator. Do not upgrade the 275 HART
Communicator.
Table 4-1 Communicator models, device descriptions, and transmitter support
Transmitter
275 HART Communicator 375 Field Communicator
Device description Support
(1)
(1) “Full” support does not include all functionality (e.g., gas standard volume flow).
Device description Support
(1)
Model 1500 AN Not available None 1500 Mass Flow Full
Model 1700 AN 1000 Mass Flow Full 1000 Mass Flow Full
Model 1700 IS 1000I Mass Flow Full 1000I Mass Flow Full
Model 2500 CIO 2000C Mass Flow
(2)
(2) See Section 4.2.2 for information on using the 275 HART Communicator with this transmitter.
Partial 2000C Mass Flow Full
Model 2700 AN 2000 Mass Flow Full 2000 Mass Flow Full
Model 2700 IS 2000I Mass Flow Full 2000I Mass Flow Full
Model 2700 CIO 2000C Mass Flow Full 2000C Mass Flow Full
HART Communicator
Notice: Upgrade 275
Software to access
new Xmtr functions.
Continue with old
description?
