48 Micro Motion Series 1000 and Series 2000 Transmitters
Required Transmitter Configuration
Figure 6-5 Configuring measurement units
6.4.1 Mass flow units
The default mass flow measurement unit is
g/s. See Table 6-2 for a complete list of mass flow
measurement units.
If the mass flow unit you want to use is not listed, you can define a special measurement unit for mass
flow (see Section 8.5).
Table 6-2 Mass flow measurement units
Mass flow unit
Unit descriptionDisplay ProLink II Communicator
G/S g/s g/s Grams per second
G/MIN g/min g/min Grams per minute
G/H g/hr g/h Grams per hour
KG/S kg/s kg/s Kilograms per second
KG/MIN kg/min kg/min Kilograms per minute
KG/H kg/hr kg/h Kilograms per hour
KG/D kg/day kg/d Kilograms per day
T/MIN mTon/min MetTon/min Metric tons per minute
T/H mTon/hr MetTon/h Metric tons per hour
T/D mTon/day MetTon/d Metric tons per day
LB/S lbs/s lb/s Pounds per second
LB/MIN lbs/min lb/min Pounds per minute
LB/H lbs/hr lb/h Pounds per hour
LB/D lbs/day lb/d Pounds per day
ST/MIN sTon/min STon/min Short tons (2000 pounds) per minute
ST/H sTon/hr STon/h Short tons (2000 pounds) per hour
ST/D sTon/day STon/d Short tons (2000 pounds) per day
Density
Temperature
Flow
Pressure
ProLink >
Configuration
Units
Off-line maint >
Off-line config
Vol (or GSV)
Density
Mass
Temperature
Pressure
Density
Temperature
Flow
Pressure
On-Line Menu >
Detailed Setup
Config field dev var
Communicator DisplayProLink II
