Configuration and Use Manual 57
Using the Transmitter
Required Configuration Optional ConfigurationUsing the TransmitterFlowmeter Startup
7.4.3 With a Communicator
To view process variables with a Communicator:
1. Press
1, 1.
2. Scroll through the list of process variables by pressing
Down Arrow.
3. Press the number corresponding to the process variable you wish to view, or highlight the
process variable in the list and press
Right Arrow.
7.5 Viewing transmitter status and alarms
You can view transmitter status using the status LED or display, ProLink II, or the Communicator.
The transmitter broadcasts alarms whenever a process variable exceeds its defined limits or the
transmitter detects a fault condition. You can view alarms with the display, ProLink II, or the
Communicator. For information regarding all the possible alarms, see Table 12-5.
You can use the display or ProLink II to acknowledge alarms.
7.5.1 Using the status LED
For these transmitters, the status LED is located on the front panel. This LED shows
transmitter status as described in Table 7-1.
7.5.2 Using the display
The display reports alarms in two ways:
• With the status LED, which reports only that one or more alarms has
occurred
• Through the alarm list, which reports each specific alarm
Note: If access to the alarm menu from the display has been disabled (see
Section 8.14.3), then the display will not list active alarms.
For these transmitters, the status LED is located at the top of the display (see Figure 7-1). It can be in
one of six possible states, as listed in Table 7-1.
Table 7-1 Transmitter status reported by the Model 1500/2500 status LED
Status LED state Alarm priority Definition
Green No alarm Normal operating mode
Flashing yellow No alarm Zero in progress
Yellow Low severity alarm • Alarm condition: will not cause measurement error
• Outputs continue to report process data
Red High severity (critical fault) alarm • Alarm condition: will cause measurement error
• Outputs go to configured fault indicators
• Model 1500 AN
• Model 2500 CIO
• Model 1700 AN
• Model 1700 IS
• Model 2700 AN
• Model 2700 IS
• Model 2700 CIO
