Configuration and Use Manual 49
Required Transmitter Configuration
Required Configuration Optional ConfigurationUsing the TransmitterFlowmeter Startup
6.4.2 Volume flow units
Two different sets of volume flow measurement units are provided:
• Units typically used for liquid volume – see Table 6-3
• Units typically used for gas volume – see Table 6-4
The default liquid volume flow measurement unit is
L/s. The default gas standard volume flow
measurement unit is
SCFM.
By default, only liquid volume flow units are listed. To access the gas volume flow units, you must
first use ProLink II to configure Vol Flow Type. See Section 8.4.
Note: The Communicator cannot be used to configure gas volume flow units. If a volume flow unit for
gas is configured, the Communicator will display “Unknown Enumerator” for the units label.
If the volume flow unit you want to use is not listed, you can define a special measurement unit for
volume flow (see Section 8.5).
LT/H lTon/hr LTon/h Long tons (2240 pounds) per hour
LT/D lTon/day LTon/d Long tons (2240 pounds) per day
SPECL special Spcl Special unit (see Section 8.5)
Table 6-3 Volume flow measurement units – Liquids
Volume flow unit
Display ProLink II Communicator Unit description
CUFT/S ft3/sec Cuft/s Cubic feet per second
CUF/MN ft3/min Cuft/min Cubic feet per minute
CUFT/H ft3/hr Cuft/h Cubic feet per hour
CUFT/D ft3/day Cuft/d Cubic feet per day
M3/S m3/sec Cum/s Cubic meters per second
M3/MIN m3/min Cum/min Cubic meters per minute
M3/H m3/hr Cum/h Cubic meters per hour
M3/D m3/day Cum/d Cubic meters per day
USGPS US gal/sec gal/s U.S. gallons per second
USGPM US gal/min gal/min U.S. gallons per minute
USGPH US gal/hr gal/h U.S. gallons per hour
USGPD US gal/d gal/d U.S. gallons per day
MILG/D mil US gal/day MMgal/d Million U.S. gallons per day
L/S l/sec L/s Liters per second
L/MIN l/min L/min Liters per minute
L/H l/hr L/h Liters per hour
MILL/D mil l/day ML/d Million liters per day
UKGPS Imp gal/sec Impgal/s Imperial gallons per second
Table 6-2 Mass flow measurement units continued
Mass flow unit
Unit descriptionDisplay ProLink II Communicator
