CONTENTS
INTRODUCTION 7
I. FIRST STEPS WITH PRO-E 9
1. Descriptive diagrams 11
2. Using the edger 13
a. Turning on the edger 13
b. Switching off the edger 13
c. Using the touch screen and keypads 14
d. Edging screen 15
II. EDGING A LENS 17
1. Edger working environment 19
a. Menu screen 20
b. Calling up a shape 22
c. Lens set-up and feeling 22
2. Perform a Beveling 24
a. Automatic beveling 25
b. Legend screen for customized bevels 26
c. Customized beveling 27
d. Modifying the bevel curve 29
e. Modifying the bevel curve at a particular point 30
f. Displacing the bevel curve 31
3. Perform a high-base bevel 32
a. Captioned screens 33
b. High-base beveling 34
4. Perform a Step bevel 40
a. Captioned screens 41
b. Perform a Step bevel 42
5. Grooving 49
a. Automatic grooving 50
b. Customized groove legend screen 51
c. Customised grooving 52
d. Modifying the groove curve 54
e. Modifying a point in the groove curve 55
f. Displacement of the groove curve 56
6. Produce a Flat-edge finish 56
7. Do a mixed job 57
a. Legend screens 58
b. Configuring the mixed finish 60
8. Perform a Drilled job 62
a. Automatic drilling 63
b. Legend screen for customized drilling 64
c. Customized drilling 65
9. Perform a Polishing 67
10. Chamfering 67
11. Perform a Retouching 68
