• Press to move it towards the rear surface of the lens.
The curve cannot be moved more than the minimum distance between the front and rear surfaces
observed on the bevel before the modification.
The position of the bevel as well as the distances between the crest of the bevel and the front and
rear surfaces of the lens are displayed in the zoom window at the position of the cursor.
Press the “cycle start” button (front face) or .
Press to go back to the customized bevel finish screen.
For the second lens, the customized bevel icon is pre-selected and the trajectory modification icon is
displayed.
f. Displacing the bevel curve
The displacement of the bevel curve makes it possible to move the bevel without modifying its curve.
Press from the customized bevel finish screen.
You will access the trajectory modification screen.
Press to select the displacement of the bevel curve.
Use the and buttons to displace the bevel curve:
• Press to displace it towards the front surface of the lens.
• Press to displace it towards the rear surface of the lens.
The position of the bevel as well as the distances between the crest of the bevel and the front and
rear surfaces of the lens are displayed in the zoom window at the position of the cursor.
Press the “cycle start” button (front face) or .
The edging cycle starts.
When the edging cycle is finished, the retouch screen is displayed.
