Essilor Pro-E 700 edger User Manual

For the clips and , by default, edging is configured as follows:
Material
Finishing wheel
Edging mode
Type of cycle
Polishing
Press to start the cycle.
Re-start the procedure for as many times as you have Chemistrie clips
TM
to perform.
14. CARRY OUT A HALF JACKET JOB (PRO-E 700)
We highly recommend that you edge a test lens before carrying out the edging of the final lens.
Preferably use a test lens that has a base unit equivalent to the ophthalmic lens.
a. Outline the step bevel trajectory on a Half Jacket shape
Call up the form
Press to call up the desired shape located on the tracer.
The shape is displayed on the edger work screen.
>
10
1
USER MANUAL> II. EDGING A LENS
81
Pro-E 600_Pro-E 700 > v1 -10.18
