To do a mixed finish, you need to define the points between which the two types of finish will be done. Only
the customized mode is thus accessible.
a. Legend screens
Main screen for mixed jobs
1. Modes available for a mixed finish
◦ Automatic mode: the position of the bevel or groove is automatically calculated according to
the information acquired when tracing the frame and feeling the lens.
◦ Front surface tracking: the crest of the bevel or the middle of the groove is positioned at a
constant distance from the front surface.
◦ Distributed mixed finish: the crest of the bevel or the middle of the groove is positioned in
proportion to the thickness of the lens, with respect to the front surface.
2. Access to the area defining screen
Access on a 1:1 scale.
3. Cursor movement
The cursor is represented by the green square along the shape. To move it, select it directly or use the
and buttons.
4. Settings for area 1
◦ Bevel finish
