Display on the OSD:
*PL11/03* LEFT 06:42:22
V Mix 02:25 Spd.Unk
A Mix*02:25 A.Del. 00:00
IN-00:00:00 OUT+00:00:27
LOOP:
12:23:45:13 00:07:13 100
112B/04 ClipName 999/999
Swapping Audio Track in Manual Mode
If the Manual mode is selected for the Swap audio tracks parameter value in the
Operational Setup menu (p.3.2 F4), the swap operates in a similar way but asks the
operator which track to swap when setting the swap points.
1. Select the original track:
◦ In 2-Track mode: select between the tracks 1,2 or MENU to cancel.
◦ In 4-Track mode: select among the tracks 1 to 4, or MENU to cancel.
◦ In 8-Track mode: select among the tracks 1 to 8, or MENU to cancel.
◦ In 16-Track mode: select among the tracks 1 to 16, or MENU to cancel. The
tracks 1-8 are displayed on the first page and the tracks 9-16 are available via F10
on the second page.
◦ Use the function keys to select the track to change.
2. When the choice is made, the operator selects by which track the selected one has to
be replaced:
◦ In 2-Track mode: select the new track between 1, 2 or 0.
◦ In 4-Track mode: select the new track among 1 to 4, or 0
◦ In 8-Track mode: select the new track among 1 to 8, or 0
◦ In 16-Track mode: select the new track among 1 to 16, or 0. The tracks 1-8 are
displayed on the first page and the tracks 9-16 are available via F10 on the second
page.
◦ Several swap points can be set on the same timecode (for ex. 1 -> 3, 2 -> 4).
Note
Selecting track 0 will mute the output until the next swap point or the end of the
clip.
112 5. Playlist Management
EVS Broadcast Equipment SA Issue 12.05.A- May 2014
