Hi-Motion II Camera
Camera Names
The cameras manufactured by NAC/Ikegami are sold as Hi-Motion II cameras on the
market.
Application Start
At application start, this camera is in ARM mode and the recording starts on the first
memory block.
Parameter Values
The tables below list the parameter value, or value range that are specific to the camera.
The configuration parameters are defined in the Multicam Configuration window,
Operation page, Hypermotion controller section.
Configuration Parameter Value
Port RS422
Protocol Sony 9-PIN
The operational parameters are defined in the Hypermotion mode of the Remote Panel, in
the LCD secondary menu.
Operational Parameter Value Range Default Value
# Blocks 1 to 4 1
Pre-Roll from 00s00fr to 5s00fr 00s00fr
PGMSpeed 50, 100, 200, 300, 400,1000% 100
2nd Lever +/- 1000%, 0-1000% +/- 1000
Specific Behavior of Remote Panel Keys
• RECORD: The Remote beeps if the CAM key refers to an empty block.
• RECORD: Pressing this key while the current block is recording does not send any
command to the camera.
• TAKE: This key is operational in ARM mode.
• CLEAR: Press this key to delete the current memory block data.
220 9. Advanced Control Modes
EVS Broadcast Equipment SA Issue 12.05.A- May 2014
