Layout Adjustment
203
Fax
4
2 Select a preset ratio, or specify a value.
Note • If a magnification is specified in [Reduce/
Enlarge], [Rotate 90 degrees] does not
function.
îš„Variable %
Specify a ratio in the range from 50 to 400% in 1% increments. To specify a value, use
the numeric keypad or [+] and [-].
îš„Preset %
z
100%
Scans at the same size as the original.
z
Auto %
If the scan width of the document exceeds the maximum image size, the scanned
image is rotated or reduced to fit the maximum size.
When speed dialing is used, the maximum image size will be the size registered in
the address number. When speed dialing is not used, the maximum size will be A3.
Note • You can specify whether to rotate documents in System Administration mode. For more
information, refer to "5 Tools" > "Fax Service Settings" > "Fax Control" > "Rotate 90
degrees" in the Administrator Guide.
z
Preset ratios
Select from preset scan ratios.
You can change the default values of scan ratios other than [100%] and [Auto %]. For more information,
refer to "5 Tools" > "Fax Service Settings" > "Reduce/Enlarge Presets" in the Administrator Guide.
Stamp (Adding a Stamp when Scanning a Document)
This feature stamps a circle mark at the bottom corner of each document page when it
is fed through the document feeder. This helps you easily check if each page of the
documents has been scanned correctly.
Important • Stamps cannot be affixed on the following documents:
• Documents loaded on the document glass
• Documents suspended by pressing the <Stop> button
• Documents suspended by paper jams
• 1-sided documents longer than 600 mm
• 2-sided documents longer than 431.8 mm
• Documents not fed into the document feeder.
• Documents suspended due to memory overflow
• Documents that were being scanned when an immediate transmission was suspended
Note • This feature does not appear for some models. An optional component is required. For more
information, contact our Customer Support Center.
