Garmin GI 275 User Manual

190-02246-10 GI 275 Part 23 AML STC Installation Manual
Rev. 11 Page A-4
Figure A-3 GI 275 J2752/P2752 Connector (Looking at Unit)
CAUTION
Pins highlighted in gray are not present in GI 275 ADAHRS units (P/Ns 011-04489-10 and
011-04489-30) and should be treated as Not Connected. All pins listed in Table A-3 are
present in GI 275 ADAHRS+AP units (P/Ns 011-04489-20 and 011-04489-40).
Table A-3 J2752/P2752 Connector
Pin Function I/O Pin Function I/O
1 DISCRETE OUT 7 LO OUT 40 DISCRETE OUT 8 LO OUT
2 SPARE --
41 AP INTERLOCK RELAY COM IN
3 GYRO VALID COMMON -- 42 GYRO VALID RELAY NC OUT
4 DISCRETE IN 5 LO IN 43 DISCRETE IN 6 LO IN
5 VERTICAL -FLAG OUT OUT 44 VERTICAL SUPERFLAG OUT
6 PITCH AC OUT HI OUT 45 ROLL AC OUT LO --
7 26 VAC REF LO IN 46 10 VAC REF LO IN
8 HEADING SYNCRO X OUT 47 HEADING SYNCHRO Z --
9 VERTICAL +UP OUT OUT 48 LATERAL +LEFT OUT OUT
10 LATERAL +RIGHT OUT OUT 49 TO/FROM -FLAG OUT OUT
11 RADAR ROLL HI OUT 50 RADAR ROLL LO --
12 CAN LO I/O 51 CAN TERMINATION A I/O
13 A/P HEADING ERROR HI OUT 52 A/P HEADING ERROR LO OUT
14 DISCRETE OUT 5 LO OUT 53 SPARE --
15 YAW RATE HI OUT 54 BARO CORRECTION LO IN
16 HEADING SYNCRO Y OUT 55 PITCH DC OUT OUT
17 DISCRETE OUT 9 LO OUT 56 RS-232 IN 3 IN
18 FD ENABLE HI IN 57 SPARE --
19 FD PITCH UP IN 58 FD PITCH DOWN IN
20 DISCRETE OUT 6 LO OUT 59 SPARE GROUND --
21 OAT PROBE IN LO IN 60 OAT PROBE IN HI IN
22 AP INTERLOCK RELAY NC -- 61 AP INTERLOCK RELAY NO OUT
23 GYRO VALID RELAY NO OUT 62 OAT PROBE POWER OUT
24 VERTICAL +FLAG OUT OUT 63 LATERAL +FLAG OUT OUT
25 LATERAL SUPER FLAG OUT 64 PITCH AC OUT LO OUT
26 ROLL AC OUT HI OUT 65 26 VAC REF HI IN
27 10 VAC REF HI IN 66 LATERAL -FLAG OUT OUT
28 SPARE -- 67 SPARE GROUND --
29 TO/FROM +FLAG OUT 68 VERTICAL +DOWN OUT OUT
30 RADAR PITCH LO -- 69 RADAR PITCH HI OUT
31 CAN HI I/O 70 CAN TERMINATION B I/O
32 A/P COURSE ERROR HI OUT 71 A/P COURSE ERROR LO OUT
33 SPARE -- 72 DISCRETE OUT 4 LO OUT
34 ROLL DC OUT OUT 73 YAW RATE LO --
35 BARO CORRECTION HI OUT 74 SPARE GROUND --
63646566676869707172737475767778 62
61 60
59 58 57 56 55 54 53 52 51
1
23
45
67891011131415
1617
12
1920
2125 24 23 22
18
2627282930313233
34
3536373839
404142
43
4450 49 48 47 46 45
