Garmin GI 275 User Manual

190-02246-10 GI 275 Part 23 AML STC Installation Manual
Rev. 11 Page B-70
NOTES CONTINUED
Figure B-25 Traffic Advisory System Interconnect
Sheet 3 of 3
SPLICE WITH WEATHER RADAR STABILIZATION OUTPUT (IF INSTALLED) IS ALLOWED.
ARINC OUT TO THE GI 275 IS NOT USED IF CONNECTED VIA ETHERNET.
THESE STRAPS SET THE HEADING INPUT SOURCE TO ARINC 429. REFER TO THE MANUFACTURER’S
INSTALLATION MANUAL FOR ADDITIONAL STRAPPING INFORMATION.
SPLICE WITH GPS NAVIGATOR ARINC OUTPUT (IF INSTALLED) IS ALLOWED.
THE HSDB CONNECTION TO THE GTX 345 SHOWN HERE ALSO PROVIDES THE TRANSPONDER CONTROL
INTERFACE, IF APPLICABLE.
14
15
16
17
18

Garmin GI 275 Specifications

General

Type	Electronic Flight Instrument
Display Type	LCD
Power Input	14 or 28 VDC
Operating Temperature Range	-20°C to +55°C
Brightness Control	Automatic and Manual
Certification	TSO-C113
Interfaces	ARINC 429, RS-232
Mounting	Panel Mount
