Pneumatic specifications
All gases supplied to the system must be medical grade.
Gas supplies
Pipeline gases O2, Air, N2O
Cylinder gases O2, Air, N2O (3 cylinder maximum)
Cylinder connections Pin indexed
Nut and gland DIN-477
Large cylinder kit available for O2 and N2O
Primary regulator output
pressure
Pin indexed: The primary regulator is set to
pressure less than 345 kPa (50 psi).
DIN-477: The primary regulator is set to
pressure less than 414 kPa (60 psi).
Pressure-relief valve Approximately 758 kPa (110 psi)
Pipeline connections
(filtered)
DISS-Male; DISS-Female; DIN 13252; AS
4059 (Australian); S90-116 (French Air
Liquide); BSPP 3/8 (Scandinavian) or NIST
(ISO 5359). All fittings available for O2, Air,
and N2O.
Pressure displays On system display.
Pipeline inlet pressure 280-600 kPa (41-87 psi)
Flush flow 25 l/min to 75 l/min
Internal O2 supply pressure
at which N2O shutoff
O2 pipeline less than 252 kPa (36 psi).
O2 cylinder less than 2633 kPa (381 psi).
ACGO port relief
A relief valve on the vaporizer manifold limits the fresh gas pressure
at the ACGO port to 55 kPa (8 psi) at 45 l/min.
Non-circle circuit relief
A relief valve limits the fresh gas pressure at the inspiratory port to
27 kPa (4 psi) at 55 l/min when non-circle circuit is selected.
CAUTION
Aisys CS²
11-6 2067226-001
