Physical specifications
All specifications are approximate values and can change without
notice.
Do not subject the system to excessive shock and
vibration.
Do not place excessive weight on flat surfaces or
drawers.
Maintain system balance. When using rails or dovetails,
distribute equipment on each side of the system. Uneven
system balance could cause the system to tip.
System Height 151 cm
System Width 80 cm
System Depth 89 cm
Nominal machine mass (including
three cassettes)
190 kg
Maximum configured mass (includes
external cylinders and maximum
loads on all mounting and storage
locations)
500 kg
Top of machine weight limit 45 kg
Optional top shelf weight limit,
includes top of machine weight
45 kg
Machine drawer weight limit 8 kg
Casters 13 cm
LCD and touchscreen display 304 x 228 mm (38 cm diagonal)
Lower dovetail loading
Maximum allowable lower dovetail loading is 22.7 kg and 16.2 Nm.
See "System overview" for the location of the lower dovetail.
