GE auisys cs2 User Manual

0
0
AC.22.039
5
10
15
20
25
10 20 30 40 50 60 70 80
Figure 11-1 • Lower dovetail load in kg (vertical) versus load distance
from the lower dovetail in cm (horizontal).
Upper dovetail loading
Maximum allowable upper dovetail loading is 11.3 kg and 54 Nm.
See "System overview" for the location of the upper dovetail.
5
6
7
8
9
10
11
12
40 45 50 55 60 65 70 75
AC.22.020
Figure 11-2 • Upper dovetail load in kg (vertical) versus load distance
from the upper dovetail in cm (horizontal).
11 Specifications and theory of operation
2067226-001 11-17
