Condenser
Use the optional condenser to remove water in the system that is
produced from the reaction of CO2 gas with the absorbent. The
condenser is connected between the outlet of the absorber canister
and the inlet of the circuit module. Moisture in the gas is condensed
into water droplets, which run into the condenser’s reservoir.
12
3
AB.82.043
1. Drain button
2.
Reservoir
3. Condenser
Figure 3-7 • Condenser
Draining the condenser
1. Visually check the condenser reservoir daily. Drain the reservoir
daily.
2. Place a container under the reservoir.
Aisys CS²
3-38 2067226-001
