Operation
Printed in U.S.A. 101 50940411/G0219
Hydraulics Control Lock
The hydraulics control are locked-out whenever
either of the safety bars/arm rests are in the raised
position (B, Fig. 95), the operator’s seat is
unoccupied or the cab door is open.
NOTE:
Raising the safety bars/arm rests also
applies the parking brake.
Always raise the safety bars/arm rests to lock
out hydraulics control and apply the parking
brake whenever leaving the machine
unattended.
Fig. 95 – Safety Bars/Arm Rests in Raised
Position
B
