Printed in U.S.A. 191 50940411/G0219
Schematics
Schematic Conventions
Table 57: Harness Names / Circuit No. Sets - Circuit Types Within Sets / Wire Colors
Harness Naming Conventions Circuit Sets Wire Color Abbreviations
Harness Name
Circuit No.
Sets
Circuit Types Within Set Wire Color Abbreviation
HC = Harness/Chassis 1 – 299 12 Volt Grounds Red R
HE = Harness/Engine 300 – 399 Low Voltage Grounds Pink PK
HM = Harness/Operator (Controls) 400 – 599 12V Power Orange O
HR = Harness/ROPS 600 – 699 5V Power Yellow Y
HD = Harness/Rear Door 700 – 799 CAN, Data Link White W
HL = Harness/European Lighting 800 – 999 Engine, Engine ECU Gray GY
HA = Harness/Power-A-Tach 1000 – 1199 Hydraulic Controls Light Blue LTBE
HP = Harness/High-Flow Attachments 1200 – 1399 Lights Blue/Dark Blue DKBE
BC = Battery Cable 1400 – 1499 Emission Controls Violet V
HJ = Jumper Lead 1500 – 1599 Safety Systems Light GreeN LTGN
FLY = Flying Leads & Device 1600 – 1699 Auxiliary Circuits Green GN
BBAR = Buss Bar 1700 – Un-Defined at this time Dark Green DKGN
Tan T
Brown BN
Black BK
