Operation
Printed in U.S.A. 109 50940411/G0219
NOTE: Depending upon the attachment, an
adapter harness may be necessary. Refer to the
documentation supplied with the attachment, or
contact you dealer.
Working with Buckets
Buckets are mainly used for digging, loosening,
lifting, transporting and loading loose or solid
materials.
Read the “Safety” section in this manual,
starting on page 19, before working with a
bucket. Pay special attention to the “During
Operation” information, starting on page 21.
Always follow the information included in the
“Safety” section. Serious injury or death can
occur if the safety information is not followed.
Make sure the bucket is securely attached to the
hitch before starting work. See “Connecting
Attachments” on page 104.
Follow the recommendations in “Fields of
Application” on page 14.
Digging Tips
When completing a digging task:
• When digging in a pit, exit the pit outside the dig-
ging line, through an area as level as possible.
• If possible, dig by removing adjacent strips.
• Drive forward when transporting a full bucket
out of the digging area.
• Drive in reverse when transporting a full bucket
down a steep slope.
Pin Description
Connector
Pin
Amp
Ground B 15
Power (with key ON) K 15
Not Assigned L N/A
Not Assigned M N/A
Not Assigned N N/A
Not Assigned P N/A
Not Assigned J N/A
Table 34: 14-Pin Joystick and Pin Assignments
Joystick
Switch
Switch
Position
Switch
Type
Connector
Pin
Amp
