Maintenance
Printed in U.S.A. 153 50940411/G0219
P 10A Tail Light, Backup Alarm, Radio
Q 20A HVAC Condenser Fan
R 15A
Interlocks, 2-Speed, Hydraglide™, Lift,
Tilt (Controller 3)
S 30A ECU Constant Power
T 20A Work Lights
U 20A
Lift, Standard/High-Flow Aux. Hydraulic
Controllers (Controller 1 & High-Flow
Module)
V 30A HVAC Relay
W 10A Auxiliary Power Outlets
X 10A Parking Brake Relay, Power-A-Tach®
Y 10A Horn
Z 20A Wipers
AA N/A Not Used
BB 10A Ignition
CC 15A Track Tension, Self Level
DD 10A Display, Joysticks, Seat/Door Switches
EE 80A
Power Relay, Ignition Switch, Dome
Light
FF 30A Power-A-Tach® System Hitch
GG 100A Glow Relay Fuse
Table 40: RT250 (SN 70501 and Up) Engine
Compartment Fuses
