150
Saving Data
4
Under [Type], select the type of data to save.
Waveform
Saves waveform data.
Screen shot Saves a screen image. (PNG format)
Settings Saves the instrument’s setting conditions.
Calc results Saves numerical calculation results.
A2L le Used by the XCP master.
See “9.10 Sending Measurement Data Using XCP on Ethernet” (p. 293).
(When [Type] is set to [Waveform])
Under [Format], select the le format.
Binary
Saves data in the instrument’s dedicated format (binary format).
You will be able to load binary-form data on the instrument and with the Logger Utility.
Text Saves data in text format.
Although you will be able to load text-form data with spreadsheet software, you will not
be able to load it on the instrument or with the Logger Utility.
MDF(MF4) Saves waveform data in the MDF format (Ver. 4).
These les can be loaded on a PC using a waveform viewer that supports the MDF
format. They cannot be loaded by the instrument or the Logger Utility.
If [Text] is selected, congure the text format settings under [Settings...].
See [Settings...] of [Text] in “Auto save (real-time save)” (p. 146).
(When [Type] is set to [Waveform])
Under [Range], select the range of data to save.
All
Saves the waveform for the entire recorded length, without regard to the A/B cursors.
A-B Saves the waveform between the A and B cursors.
Start-A Saves the waveform from the beginning to the A cursor.
Start-B Saves the waveform from the beginning to the B cursor.
A-End Saves the waveform from the A cursor to the end.
B-End Saves the waveform from the B cursor to the end.
See “Specifying a waveform range” (p. 97).
(When [Format] is set to [Text])
Under [Downsampling], select whether to perform downsampling.
When set to [ON], the size of the saved data le will be reduced.
OFF
, ON
(When [Downsampling] is set to [ON])
Under [Decimation factor], select the decimation factor.
1/2
to 1/100000
Example: If set to [1/5], 1 data point out of every 5 data points will be left.
