Infotainment system 87
2. Press
MENU•TUNE
(14).
The menu options for the current
device are displayed (except
Bluetooth
®
audio).
Bluetooth
®
hands-free
phone device
T
o select Bluetooth
®
phone mode:
1. Press
/
(17).
T
o display Bluetooth
®
options for the
relevant function:
2. Press
/
(17)
88
90
