Honeywell FlexLine SmartServo 954 User Manual

COMMISSIONING
Part No.: 4417340 Revision 1 Service Manual 129
954 SmartServo FlexLine
Product Temperature
☛ The following entities must be set by Engauge or HART
SmartView for a correct functioning of the FII-VT module in an
instrument.
NOTE: Using Engauge, following entities are set within the Engauge
Product temperature tab.
 RTD 3 spots (see Figure 7-19 left side)
Name Explanation Value Range Default
[Element type]
The supported element
type is: SPL
3 characters
<SPL>
<--->
[Number of elements]
The number of elements a
RTD probe has
<1 .. 3> <0>
[Lowest element offset]
The distance from tank zero
till the lowest position of the
multi-RTD probe.
So not used for the 3-wire
version and it must be 0.
floating point number:
<-x.x .. +x.x>
MUST BE <0.0>
<80.0>
[RTD element positions]
The positions of the RTDs
from tank zero level
3 floating point numbers:
<-x.x .. +x.x>
Note: Only actually used
elements to be entered.
<0,0,0>
 Multi RTD probe (see Figure 7-19 right side)
Name Explanation Value Range Default
[Element type]
The supported element
type is : SPL
3 characters
<SPL>
<--->
[Number of elements]
The number of elements a
RTD probe has
<1 .. 14> <0>
[Lowest element offset]
The distance from tank zero
till the lowest position of the
multi-RTD probe
floating point number:
<-x.x .. +x.x>
<80.0>
[RTD element positions]
The positions of the RTDs
from the lowest position of
the probe.
So not tank zero level!
14 floating point numbers:
<-x.x .. +x.x>
Note: Only actually used
elements to be entered.
<0,0,0,0,0,0,0,0,0,0,0,0,0,0>
