COMMISSIONING
238 Service Manual Part No.: 4417340 Revision 1
954 SmartServo FlexLine
7.7.1.1 Wire weight
The wire weight compensation requires one configuration parameter.
This parameter is automatically set correctly when the correct
[Measuring range and wire type] is chosen (refer to section 7.4)
When <
No measuring range selected> or <Other measuring range or wire type> is
selected the wire weight needs to be set manually:
Entity name Default Value Explanation
[Wire weight per unit of length]
< 0.00025 [kg/m] >
Wire weight in kg per meter. The default value
is for stainless steel 316.
7.7.1.2 Unbalance
The unbalance compensation needs a table with the measured
unbalance. This table is automatically generated when performing a
balance test.
Note: Whenever the drum has been (temporarily) removed from the
gauge or the drum is replaced by another one, a new balance test must
be performed to update the unbalance table.
