Honeywell FlexLine SmartServo 954 User Manual

COMMISSIONING
144 Service Manual Part No.: 4417340 Revision 1
954 SmartServo FlexLine
Name Explanation Value Range Default
[Element weighing factor]
Each element can individually be
given a weighing factor, which is
applicable if the calculation
method is CUSTOM.
floating point numbers:
<-x.x .. +x.x>
<1.0>
[Gauge temperature scale]
Determines whether the IPTS-
68 or ITS-90 scale is used.
<IPTS-68>
<ITS-90>
<ITS-90>
[Low element usage]
See Figure 7-24
<No Exclusion>
<Static Exclusion>
<Dynamic Exclusion>
<No Exclusion>
[Low element behaviour]
See Figure 7-24
<Temp To Fail>
<Temp To Last Valid>
<Temp Use First Element>
<Temp Use Second Element>
<Temp To Fail>
[Temperature element exclude
zone]
See Figure 7-24
floating point number:
<-x.x .. +x.x>
<1.0>
[Smoothing level]
See Figure 7-24
floating point numbers:
<-x.x .. +x.x>
<0.0>
[MPT element position mode]
[Only for MPT]
Determines whether the element
positions are automatically
calculated (based on sensor
length) or manually entered.
<Automatically>
<Manually>
<Automatically>
[RTD element positions]
[Only for MPT]
If MPT element position mode
is MANUALLY then here the
positions can be filled in.
floating point numbers:
<-x.x .. +x.x>
<0.0>
[Averaging constant filter]
Enables or disables a
averaging constant filter.
<enable>
<disable>
<enable>
[Averaging constant]
Value of how much of the old
calculated value is used with
respect to the new calculated
value
<0.0 .. 1.0> <0.9>
[Temperature range check]
Enables or disables the fact that
an element which is outside a
temperature range will lead to
temperature fail.
(Se
e
a
l
s
o
Figure
7
-
23
)
<enable>
<disable>
<disable>
