COMMISSIONING
Part No.: 4417340 Revision 1 Service Manual 221
954 SmartServo FlexLine
Name Value Range Default Value Description
[Contact 1
hysteresis]
< 0 – 3.402823 × 10
38
>
(meters)
< 0.010 > A value relative to the threshold
that will determine the point at
which deactivation of a contact 1
safe state occurs after activation
by an overfill or underfill
condition.
For an underfill, deactivation
occurs when the product level is
above (threshold + hysteresis).
For an overfill, deactivation
occurs when the product level is
below (threshold – hysteresis).
[Contact 1
safety function
status]
(RO)
Status:
< H >, < O >, < U >, < W >
Status Code:
Defined in Section 7.3.13.1
Status:
< H >
Status Code:
NO ERROR
H: Healthy
O: Overfill condition
U: Underfill condition
W: Warning condition, safe state
is active, or proof test is overdue
(status code is NO ERROR)
[Contact 1
safety
shutdown
counter]
(RO)
< 0 – 3.402823 × 10
38
>
< 0 > The number of contact 1 safe
state activations that have
occurred since commissioning.
[Contact 1
safety
shutdown
reason]
(RO)
Safety Function Status
Code
NO ERROR The safety function status code
identifies the reason for the last
time a contact 1 safe state
activation occurred.
[Contact 1
switch count]
(RO)
< 0 – 3.402823 × 10
38
>
< 0 > The number of contact 1
closures, or transitions from safe
state to normal state, since
commissioning.
[Contact 1
Start proof
test]
Command Initiates a contact 1 proof test if
an actual contact 1 safe state is
not currently active. Upon
activation, contact 1 will open to
simulate a safe state. An active
poof test will terminate if an
actual contact 1 safe state is
activated, or if the contact 1
proof test timeout value is
exceeded.
